Name of Product: Handjet EBS 260
Brand:
EBS
Feature:
Communication with the printer is simple and versatile: via WiFi, Bluetooth or USB. The printer can be logged into an existing WiFi network and operated through the Firefox browser without installing additional software
Product Description
Touchscreen
Coloured display with hardened glass,
9cm diagonal
Number of nozzles
32
Nozzle diameter
150 μm, optional 200 μm und 120 μm
Print image height
7 - 56 mm
Minimum size
of object to be printed on
from 40 mm
Working position of the printer
any
Printer memory
2 Gigabyte
Memory blocks for projects
>50.000 Projekte with 10.000 characters or more
Graphics, logos, graphical special characters
Black & white PNG data can be imported up to a height of 32 dots.
Capable of Unicode
Yes
TrueType Fonts installable
Yes
Special characters
National, diacritical characters, graphical info-, warning and transport characters
Special register
Date, time, expiry date, incremental and decremental counter, universal counter (piece, palette, etc. ..)
Date format editable
yes
Programming the printer
Via the built-in touchscreen, directly on the website of the specific printer in the Firefox browser or via Offline Editor (included)
Special functions
Laser positioner, automatic measuring of objects
Optional special functions
Master-Slave Bluetooth connection with input devices such as; scanner, database functions, php-script administration
Power supply
External power supply 24V, 1,25A
Operating time
Up to 16 hours
Ink base
Quick-drying inks; ethanol, acetone or MEK-based, also pigmented (to be specified when ordering)
Ink types
Different colours; (black, blue, red, green, yellow) UV legible, (security inks), food-grade inks, inks for wood, concrete, pigmented inks for dark surfaces
Cartridge volume
200 ml
Capacity per cartridge
> 200.000 characters in Matrix 7x5
Operating pressure
Nominal 0,35 bar, internal mini-compressor
Operating temp. range
5°C - 40°C
Storage / transport temperature
0°C - 45°C
Humidity
Max. 90% without condensation
Weight incl. cartridge
1,65 kg
